Mitsubishi MELSEC Q Series User Manual

13
MULTIPLE CPU SYSTEM CONCEPT
13.1 Mounting Position of CPU Module
13 - 6
9
UTILITY OPERATION
10
FUNCTIONS AND PROGRAMMING
11
OVERVIEW OF MULTIPLE CPU SYSTEM
12
MULTIPLE CPU SYSTEM CONFIGURATION
13
MULTIPLE CPU SYSTEM CONCEPT
14
COMMUNICATIONS BETWEEN CPU MODULES
15
PARAMETERS ADDED FOR MULTIPLE CPU
16
PRECAUTIONS FOR USE OF AnS SERIES MODULE
* 1 The No. of CPUs indicates the value set in the "No. of CPU" on the <<Multiple CPU setting>> tab
of the C Controller setting utility.
Refer to the manuals of the corresponding CPU modules for the programmable controller CPU
and Motion CPU.
Table13.3 Mounting position of CPU module
No. of CPUs*
1
Mounting position of CPU module
2
3
CPU 0 1 2
: Slot numbe
r
CPU 0 1 2
Power supply module Basic model QCPU C Controller module
CPU 0 1 2
C Controller module Power supply module Basic model QCPU Motion CPU
CPU 0 1 2
Power supply module Basic model QCPU CPU (Empty) C Controller module
