15
PARAMETERS ADDED FOR MULTIPLE CPU SYSTEM
15.1 Parameter List
15 - 2
9
UTILITY OPERATION
10
FUNCTIONS AND
PROGRAMMING
11
OVERVIEW OF
MULTIPLE CPU
SYSTEM
12
MULTIPLE CPU
SYSTEM
CONFIGURATION
13
MULTIPLE CPU
SYSTEM
CONCEPT
14
COMMUNICATIONS
BETWEEN CPU
MODULES
15
PARAMETERS
ADDED FOR
MULTIPLE CPU
16
PRECAUTIONS FOR
USE OF AnS SERIES
MODULE
(2) C Controller setting utility setting items needed for multiple CPU system
operation
Table15.1 indicates the setup necessity and consistency of the C Controller setting
utility items required for using a multiple CPU system.
Table15.1 Setting list for the multiple CPU system and I/O assignment (control CPU)
C Controller setting utility item
Necessity
of setup
*1
Same
setting
*2
Reference section
I/O
assignment
setting
I/O assignment
6.6.2
Type ----
Model name ---- ----
Points ----
Start XY ----
Base setting
6.3
Base model name ---- ----
Power model name ---- ----
Extension cable ---- ----
Slots ----
Switch setting ---- ---- 4.12
Detailed setting
4.10
Error time output mode ---- ----
H/W error time CPU operation
mode
---- ---- 4.11
I/O response time ---- ---- 4.9
Control CPU 15.1.5
System setting Points occupied by empty slot ---- ---- 6.6.2
Multiple CPU
setting
No. of CPU 15.1.1
Operating mode 15.1.2
All CPUs can read all inputs
15.1.3
All CPUs can read all outputs
Refresh setting
15.1.4
Send range for each CPU
* 1 Necessity of setup
: Items required for multiple CPU system (operations not possible if not set up)
: Items that may be set up for multiple CPU system if necessary.
(Operations carried out with the default values when not set up)
---- : Items that are the same as single CPU system.
* 2 Same setting
: Items that must be the same settings for all CPU modules on the multiple CPU
system.
:
Items that must be the same settings for all C Controller modules and
programmable controller CPUs in the multiple CPU system (items that are not for
Motion CPUs)
---- : Items that can be set up individually for each CPU module on the multiple CPU
system.
To Next Page
