18.4 Error Code and Error Message Lists
18.4.2 Actions by Event No.
18
TROUBLESHOOTING
(1) Corrective actions for "MQbfDrv" events by event Nos.
Corrective actions for events that may occur in "MQbfDrv" are listed below by event
Nos.
The fixed value, 49152 (0xC000) is stored into the upper word part of the event No.
* 1 Only the first error code detected during module initialization is displayed.
Table18.12 Corrective actions for "MQbfDrv" events by event Nos.
Event No. Event Corrective action
0xC000011E Failed to secure the memory area necessary for starting the driver.
Increase the system memory.
Reduce the memory usage of other programs.
0xC0000127 SYSTEM WDT ERROR occurred.
Section 18.3 (3) error code 5000
0xC0000131 USER WDT ERROR occurred.
Section 18.3 (3) error code 5001
0xC0000201 AC/DC DOWN occurred.
Section 18.3 (3) error code 1500
0xC0000202 CONTROL-BUS.ERR. occurred.
Section 18.3 (3) error code 1413, 1414,
1415, 1416
0xC0000204 UNIT VERIFY ERR. occurred.
Section 18.3 (3) error code 2000
0xC0000206 FUSE BREAK OFF occurred.
Section 18.3 (3) error code 1300
0xC0000207 SP.UNIT DOWN occurred.
Section 18.3 (3) error code 1401, 1403
0xC0000208 CONTROL-BUS. ERR. occurred.
Section 18.3 (3) error code 1412
0xC0000209 SP.UNIT LAY ERR. occurred.
Section 18.3 (3) error code 2100, 2103,
2106, 2107, 2108, 2120, 2121, 2122, 2124,
2125, 2126, 2150
0xC000020A PARAMETER ERROR occurred.
Section 18.3 (3) error code 3000, 3001,
3010, 3012, 3014
0xC000020B
An error occurred during module initialization.
*1
Take corrective actions corresponding to the
error code displayed in the event information
( Section 18.3 (3)).
0xC000020E A CPU module built-in battery error occurred.
Section 18.3 (3) error code 1600
0xC0000210 MULTI CPU DOWN occurred.
Section 18.3 (3) error code 7000, 7002
0xC0000211 MULTI EXE.ERROR occurred.
Section 18.3 (3) error code 7010
0xC0000212 MULTI CPU ERROR occurred.
Section 18.3 (3) error code 7020
0xC0000213 SP.PARAMETER ERROR occurred.
Section 18.3 (3) error code 3300, 3301,
3302, 3303
0xC0000214 LINK PARAMETER ERROR occurred.
Section 18.3 (3) error code 3100, 3101,
3102, 3103, 3104, 3105, 3107
0xC0000215 I/O INT.ERROR occurred.
Section 18.3 (3) error code 1310
0xC0000216 MAIN CPU DOWN occurred.
Section 18.3 (3) error code 1009
0xC0000217 A momentary stop occurred.
Section 18.3 (3) error code 1500
0xC0000218 LINK REFRESH TIME OVER occurred.
Section 18.3 (3) error code 5012
0xC0000219 SINGLE PS.DOWN occurred.
Section 18.3 (3) error code 1510
0xC000021A SINGLE PS.ERROR occurred.
Section 18.3 (3) error code 1520
