ENGINE ELECTRICAL ± Ignition System
16-31
IGNITION COIL
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
D Engine Cover Removal and Installation
D Resonance Tank Removal and Installation
(Refer to GROUP 15.)
D Air Cleaner Assembly and Air Intake Hose Removal
and Installation
25 Nm
1
3
2
10 Nm
Disassembly steps
1. Ignition Coil Connector
2. Ignition Coil
3. Spark Plug
To Next Page
