54A-2
CHASSIS
ELECTRICAL
CONTENTS
BATTERY 5. . . . . . . . . . . . . . . . . . . . . . . . . . .
SERVICE SPECIFICATION 5. . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 5. . . . . . . . . . . . . . . . . .
Fluid Level and Specific Gravity Check 5. . . . . .
Charging 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Testing Procedure 7. . . . . . . . . . . . . . . . . . .
IGNITION SWITCH AND IMMOBILIZER
SYSTEM* 8. . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOL 8. . . . . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING 8. . . . . . . . . . . . . . . . . . . .
IGNITION SWITCH AND IMMOBILIZER
SYSTEM 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
COMBINATION METERS 17. . . . . . . . . . . .
SERVICE SPECIFICATIONS 17. . . . . . . . . . . . .
SEALANT 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 18. . . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING 19. . . . . . . . . . . . . . . . . . .
CONTINUED ON NEXT PAGE
WARNINGS REGARDING SERVICING OF SUPPLEMENTAL RESTRAINT SYSTEM (SRS) EQUIPPED VEHICLES
WARNING!
(1) Improper service or maintenance of any component of the SRS, or any SRS-related component, can lead to personal
injury or death to service personnel (from inadvertent firing of the air bag) or to the driver and passenger (from
rendering the SRS inoperative).
(2) Service or maintenance of any SRS component or SRS-related component must be performed only at an authorized
MITSUBISHI dealer.
(3) MITSUBISHI dealer personnel must thoroughly review this manual, and especially its GROUP 52B ± Supplemental
Restraint System (SRS) before beginning any service or maintenance of any component of the SRS or any SRS-related
component.
NOTE
The SRS includes the following components: SRS-ECU, SRS warning lamp, air bag module, clock spring and interconnecting
wiring. Other SRS-related components (that may have to be removed/installed in connection with SRS service or maintenance)
are indicated in the table of contents by an asterisk (*).
