4.5.23 GUI Access Levels
There are five levels of access to the MFC control system. Access to higher levels
requires that you enter a security code. The higher level access codes are only issued
to factory trained technicians so that they can change control system settings when
they do routine maintenance and service procedures.
Access Level Code Information
1.
OPERATOR not required This is the default access level.
2.
SUPERVISOR not required Additional job locking security and air supply control.
3.
SERVICE 1973 Available to factory trained technicians.
4.
DISTRIBUTOR **** Only available on special request (sets TOTAL SET LIMIT).
5.
FACTORY **** Only available to manufacturer.
Function Operator Supervisor Service Distributor Factory
Job Unlock / Delete - job level 1 < 3 < 4 < 5 any
MENU ✓ ✓ ✓ ✓ ✓
USER SETTINGS ✓ ✓ ✓ ✓ ✓
ACCESS LEVEL ✓ ✓ ✓ ✓ ✓
CURRENT LANGUAGE ✓ ✓ ✓ ✓ ✓
LIGHTER ✓ ✓ ✓ ✓ ✓
DARKER ✓ ✓ ✓ ✓ ✓
FEEDER INFO ✓ ✓ ✓ ✓ ✓
CLEANING ✓ ✓ ✓ ✓ ✓
TOTAL SET LIMIT View only
when limit
reached
View only/
add 100
sheets if at
limit
View only/
add 5000
sets if at
limit
✓ ✓
MACHINE OPTIONS ✓ ✓ ✓ ✓ ✓
REMOTE OUTPUT (n/a) View only View only ✓ ✓ ✓
REMOTE INPUT (n/a) View only View only ✓ ✓ ✓
MEASUREMENT View only ✓ ✓ ✓ ✓
PAUSE TIME View only ✓ ✓ ✓ ✓
SPECIAL MODULES View only View only ✓ ✓ ✓
MULTI TOWER (n/a) View only View only ✓ ✓ ✓
INTER TOWER DISTANCE (n/a) View only ✓ ✓ ✓ ✓
SERVICE OPTIONS ✓ ✓ ✓ ✓ ✓
TRAYS UP/DOWN (n/a) ✓ ✓ ✓ ✓ ✓
BIN ADDRESS ✓ ✓ ✓ ✓ ✓
BIN INITIALISATION ✓ ✓ ✓ ✓ ✓
CLEAR ERRORS ✓ ✓ ✓ ✓ ✓
NETWORK SETTINGS ✓ View only ✓ ✓ ✓
SYSTEM MONITOR ✓ ✓ ✓ ✓ ✓
ADVANCED DEBUG ✓ ✓ ✓ ✓ ✓
4.5.23.1 Select an Access Level
(1) Set the main input switch to ON (I).
(2) Touch MENU on the GUI panel touch screen.
(3) Select a level from the ACCESS LEVEL drop down list.
(4) Enter the correct access code on the keypad.
