Morgana DocuMaster MFC - Service Manual 5
1. Introduction - Warning Labels
1.4 Warning Labels
The warning labels that follow are used in the DocuMaster MFC.
Warning Labels Description Location
Shows an entanglement hazard.
Black illustration on yellow
triangle.
Black text on orange caution bar
and white
background.
Hinged rear
p
anel above the
rear guard.
Shows that mains input voltages
are present.
Black figure on a yellow
background.
Mains input and
areas with high
voltage supply.
Shows that high voltages are
present.
Black text on yellow background.
High-voltage
Anti-static
transformer.
Shows high voltages behind cover.
Black figure on a yellow
background.
Hinged top
panel.
Shows protective earth bonding.
White figure on a green
background.
DRV module at
earth bonding
points.
