1.5 Orientation
Procedures or descriptions refer to the right hand (RH) or left hand (LH) side of the
machine (see Figure 1.1).
• The RH or LH is as seen from the feed bins (Front).
• The GUI touch screen is at the left
• The conveyor is at the rear.
Rear
RH Side
LH Side
Emergency Stop Switch
BookletMaker
GUI Touch Screen
Front
Figure 1.1 DocuMaster MFC Orientation
