Morgana DocuMaster MFC - Adjust the Dynatilt Home Switch

Morgana DocuMaster MFC - Service Manual 79
4. Service Procedures - Machine Adjustments and Calibration
4
Before you start:
• Do the DynaTilt motor gear play test (See Section 4.5.15.1).
• Remove the GUI panel (See Section 4.7.4).
Step Actio Information
1 Adjust the DynaTilt drive-motor
position to increase or decrease
the gear play.
• Loosen the four screws that
attach the DynaTilt drive-motor to
the LH side plate.
• Turn the DynaTilt drive-motor
clockwise around the pivot screw
to decrease the amount of gear
play.
• Turn the DynaTilt drive-motor
counterclockwise around the
pivot screw to increase the
amount of gear play.
• Tighten the screws.
2 Do the DynaTilt motor gear play
test.
(See Section 4.5.15.1).
4.5.16 Adjust the DynaTilt Home Switch
The DynaTilt home switch has two functions:
Function Description
Limit Switch Limits and sets the movement range of the DynaT
ilt
mechanism.
Home (Reference)
Switch
Gives the DynaTilt mechanism a fixed zero-reference
position
to calibrate from.
The DynaTilt mechanism is programmed to do a reference check when you:
• turn on the electrical cabinet
• press the MFC start button.
