4. Service Procedures - Replace Components - Suction Feed Bin
122 Morgana DocuMaster MFC - Service Manual
4.8.2.2 Replace the Feed Band
Step Action Information
1 Hold the suction feed head in both
hands with the support shaft facing
you.
2 Remove the drive shaft from the
feed head.
• Grip the drive shaft on both sides
of the feed head.
• Place your thumbs on top of the
feed head.
• Pull the drive shaft away from the
bearing supports and on to the
top of the feed head.
• Slide the drive shaft out from
beneath the feed band.
3 Remove the feed band. Be careful to keep the support shaft
in position.
4 Check that the separation adjuster
is calibrated correctly
.
(See Section 4.5.4).
5 Install the replacement feed band. Make sure that the central rib is on
th
e inside of the belt.
6 Install the drive shaft. Make sure that the feed band central
rib is located
the shaft grooves.
7 Do a check that the separation
adjuster is calibrated correctly
.
(See Section 4.5.4).
4.8.2.3 Install the Suction Feed Head
(1) Hold the suction feed head so that the vacuum tube is on the LH side.
(2) Put the ball socket end of the drive shaft in to the cup of the ball shaft on the LH
side plate.
(3) Push the suction feed head towards the LH side plate and locate the RH end of the
drive shaft over the clutch shaft on the RH side plate.
(4) Turn the feed band and fully locate the drive shaft on to the drive pin on the clutch
shaft.
(5) Connect the vacuum tube to the connector on the LH side plate.
