1. Introduction - Description of Operation
18 Morgana DocuMaster MFC - Service Manual
releases the sheets into a driven conveyor below. The sheets are moved directly into
the infeed of the online bookletmaker.
An interface cable from the bookletmaker is connected
directly to the gathering area
control PCB, which gives communications between the MFC and bookletmaker.
Figure 1.10 Gathering Area Interface Sockets
A reed switch sensor above the paper stop latch detects the paper in the gathering
area. If the sensor detects paper at the end of the release sequence, the paper stop
latch will remain open and the MFC will show a jam error.
