Motion Control Engineering 2000 User Manual

The Computer
5-90 Manual # 42-02-1P21
83 Floor zone
84 Position bypass count
85 Position pass count
86 System position count
87 Absolute position count
88 Position lower sequence
89 Position upper sequence
90 Position lower value
91 Position upper value
92 Landing code
93 At landing
95 Near floor
100
Port A inputs:
01 = SPD0
02 = SPD1
03 = SPD2
04 = UETS
05 = DETS
06 = SPIN7
07 = DZ
08 = DCL
09 = (n/a)
10 = SPIN8
11 = IND
12 = (n/a)
13 = MRDN
14 = DCABR
15 = DOB
16 = DCB
101
Port B inputs:
01 = DZR
02 = MABGR
03 = GSR
04 = MBAB
05 = MTAB
06 = MABT
07 = DLR
08 = DL
09 = ABD
10 = ABU
11 = ATD
12 = ATU
13 = SPIN10
14 = SPIN9
15 = ICEN
16 = CTEN
Table 5.15 Controller Board CTL B Processor Diagnostics
