Motion Control Engineering 2000 User Manual

F5: Controller Utilities/Monitoring and Reporting
5-91
5
102
Port C inputs:
01 = (n/a)
02 = MSAFL1
03 = MDZLV
04 = MABGF
05 = GS
06 = (n/a)
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
103 Port D inputs: (n/a)
104
Port E inputs:
01 = DOL
02 = DPM
03 = SPIN1
04 = SPIN2
05 = SPIN3
06 = SPIN4
07 = SPIN5
08 = SPIN6
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
105
Port F inputs:
01 = (n/a)
02 = (n/a)
03 = MHDB
04 = FLTBYPS
05 = (n/a)
06 = (n/a)
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
106 Port G inputs: (n/a)
Table 5.15 Controller Board CTL B Processor Diagnostics
