CTL Car to lobby input 31 6 HLI Heavy load input 25 5
CTLDOT Car to lobby door open timer 31 8 HLW Heavy load weigher flag 38 1
CTLF Car to lobby function 31 7 HML Home landing input 38 8
CTST Capture for test input 33 3 HOSP In car hospital emergency input flag 33 1
DBC Door close button input 20 4 HOSPH2 Hospital emergency phase 2 flag 33 2
DBCR Door close button (rear) 10 4 HSEL Hospital service select flag 2B 3
DC Down call flag 21 7 HYD1-TR0 Hydro/Traction flag 2F 6
DCA Down call above flag 2A 3 IN Inspection or access input 27 4
DCB Down call below flag 2A 7 INCF Ind. service car call cancel flag 28 3
DCC Door close complete flag 23 4 IND Independent service input 27 5
DCCR Door close complete flag (rear) 13 4 ISR In service and ready 28 4
DCF Door close function output 22 8 ISRT In service truly flag 2C 1
DCFR Door close function output (rear) 12 8 ISV In service flag 2C 2
DCLC Door close contact input 23 6 LD Level down input 29 7
DCLCR Door close contact input (rear) 13 6 LFP Lower parking floor flag 26 8
DCP Door close power output 22 7 LLI Light load input 28 1
DCPR Door close power output (rear) 12 7 LLW Light load weighing funct. input flag 28 8
DCR Down call flag (rear) 11 7 LOT Lobby door time 22 5
DHENDR Door hold end rear 33 5 LOTR Lobby door time (rear) 12 5
DDF Double ding function flag 28 6 LU Level up input 29 3
DDP Down direction preference flag 29 5 LWCE Load weighing change enable flag 38 2
DEADZ Dead zone flag 30 4 MLT Motor limit timer flag 2B 7
DHEND Door hold end 33 4 MLTDO Motor limit timer door open 27 1
DHLD Door hold input flag 27 6 MLTP Motor limit timer pilot flag 27 2
DHLDI Normal door hold input flag 30 3 NDGBPS Nudging bypass flag 23 2
DHO Door hold open flag 21 2 NDGBPSR Nudging bypass flag (rear) 13 2
DHOR Door hold open flag (rear) 11 2 NDGF Nudging function flag 30 1
DIN Door open inactive 26 4 NDS Hall door timer non-shorten 21 4
DLI Dispatch Load Input 38 4 NDSR Hall door timer non-shorten (rear) 11 4
DLK Door lock input 28 7 NUDG Nudging output 23 3
DLKS Door lock store bit 27 3 NUDGR Nudging output (rear) 13 3
DLW Dispatch load weighing function 38 3 NYDS New York door shortening flag 26 6
DMD Demand down flag 2A 8 PFG Passing floor gong output 2F 1
DMU Demand up flag 2A 4 PH1 Phase 1 return complete flag 30 2
DNDO Down direction output 29 8 PHE Photo eye input 20 7
DNS Down direction sense input 24 4 PHER Photo eye input (rear) 10 7
DOB Door open button input 20 3 PIC PI correction flag 25 1
DOBR Door open button input (rear) 10 3 R2 Absolute floor encoding #2 30 7
DOC Door open command 23 8 R3 Absolute floor encoding #3 30 6
DOCR Door open command (rear) 13 8 R4 Absolute floor encoding #4 30 8
DOF Door open function output 22 6 REAR Rear door flag 28 2
DOFR Door open function output (rear) 12 6 RUN Run flag 2B 1
DOI Door open intent flag 21 1 SAB Sabbath input 33 7
DOIR Door open intent flag (rear) 11 1 SAF Safety string input 2C 6
Table 5.4 Alphabetized Flags/Variables and Their Locations
FLAG Definition Add
Position
FLAG Definition Add
Position
