Motorola Astro XTL 5000 Basic Service Manual

June 11, 2003 6881096C73-O
9-6 Basic Troubleshooting: Power-Up Error Codes
ERROR 01/22 Tuning Codeplug
Checksum
NON-FATAL Reprogram the tuning partition.
FAIL 01/81 FLASH ROM Checksum FATAL Reprogram the radio firmware.
FAIL 01/82 FLASH ROM Codeplug
Checksum
FATAL Reprogram the codeplug.
FAIL 01/88 External SRAM Failure FATAL Turn the radio off, then on.
FAIL 01/90 General Hardware FATAL Turn the radio off, then on.
FAIL 01/92 Security Partition
Checksum
FATAL Reprogram the security partition.
FAIL 01/93 FlashPORT AUTHENT
CODE Failure
FATAL Contact the depot.
FAIL 01/98 Internal RAM Failure FATAL Turn the radio off, then on.
FAIL 01/A2 Tuning Codeplug
Checksum
FATAL Reprogram the tuning partition.
FAIL 02/81 DSP ROM Checksum FATAL Reprogram the DSP firmware.
FAIL 02/88 DSP RAM Fatal Error FATAL Turn the radio off, then on.
FAIL 02/90 General DSP Hardware
Failure
FATAL Turn the radio off, then on.
ERROR 05/10 Control Head Hardware
Error
NON-FATAL Turn the radio off, then on.
FAIL 05/81 Control Head ROM
Checksum Error
FATAL Replace the control head.
ERROR 06/10 Aux Control Head
Hardware Error
NON-FATAL Turn the radio off, then on.
FAIL 06/81 Aux Control Head ROM
Checksum Error
FATAL Replace the aux. control head.
ERROR 08/10 Siren Hardware Error NON-FATAL Turn the radio off, then on.
FAIL 08/81 Siren ROM Checksum
Error
FATAL Replace the siren.
ERROR 09/10 Secure Hardware Error NON-FATAL Replace the secure module.
FAIL 09/90 Secure Hardware Fatal
Error
FATAL Replace the secure module.
ERROR 12/10 VRS Hardware Error NON-FATAL Turn the radio off, then on.
FAIL 12/81 VRS ROM Checksum Error FATAL Replace the VRS.
ERROR 1C/10 TRC Hardware Error NON-FATAL Turn the radio off, then on.
FAIL 1C/81 TRC ROM Checksum Error FATAL Replace the TRC.
FL 01/AO Abacus IC Failure FATAL Turn the radio off, then on.
FL 02/CO Wrong microprocessor FATAL Send the radio to the depot;
replace the daughter card.
Table 9-3. Power-Up Error Codes (Continued)
Error Code Description Error Type Corrective Action
