Motorola Astro XTL 5000 Basic Service Manual

6881096C73-O June 11, 2003
Disassembly/Reassembly Procedures: Replacement Procedures 8-11
Figure 8-8. Control-Head Flex (Removed)
8. Remove the headbridge seal from the transceiver.
Figure 8-9. Headbridge Seal (Removed)
The following steps MUST be performed for secure-equipped
radios prior to removal of the cover or damage to the radio
could occur.
!
C a u t i o n
