6881096C73-O June 11, 2003
Encryption: Over-the-Air Rekeying 7-9
7.7.2 W4, W5, W7, and W9 Control Heads
1. To enter the Advanced Secure
menu, press and hold the
D
button until a tone sounds.
2. Do one of the following:
W4: Using the Mode knob, scroll to the
REKY option.
OR
W5, W7, or W9: Using the Mode rocker switch, scroll to the
REKY REQ
option.
3. To enter the rekey request menu, press and release the
SEL button.
4. To initiate a rekey request, press and release either the Sel button or the
PTT button.
The radio displays
PLS WAIT (W4, W5, W7) or PLEASE WAIT (W9).
XMIT
BUSY
Mode
Volume
Pwr
Phon
Call SelScan
Mic
Home
Dim
H/L
Dir Mon
SECURE
INDICATOR
MODE
KNOB
HOME SECURE
Model W4
Mode
Vol
Mic
Phon
Call Sel
H/L Mon Dir
PWR
Scan
XMIT
BUSY
DIM
HOME
MAEPF A
MODE
HOME
SECURE
INDICATOR
SECURE
Model W5
O #Del Rcl
Mode
Vol
Mic
Phon
Call Sel
PWR
Scan
XMIT
BUSY
DIM
HOME
1
Ste
2
3
Lck
4
Sts
5
Rpg
6
Msg
7
H/L
8
Mon
9
Dir
MODE
HOME
SECURE
INDICATOR
SECURE
Model W7
Model W9
XMIT BUSY
123
456
789
0
DIM
Pri
Non
Pri
Emer Dir
Scan
Call
Mode Vol Sel
Home
Page Rpgm
Site
Phon H/L Lock
Rcl Sql
Del
MODE SELECT
HOME
Sts Msg
Srch
SECURENET
SECURE
