June 11, 2003 6881096C73-O
5-2 Performance Checks: Test Mode
4. Pressing the Mode rocker will cause the displays to stop. The test mode menu, CH TEST, will
be displayed.
Table 5-1. Test-Mode Displays
Display Name Description Appears
SERVICE Indicates the radio has entered test mode Always
Radio Host Software
Version
The version of radio firmware Always
DSP Software Version The version of firmware being used by the
DSP
Always
EMC Secure Version Version of the encryption hardware When the
radio is secure
equipped
Encryption Firmware Firmware version for encryption When the
radio is secure
equipped
Encryption Type 1 Type of encryption being used When the
radio is secure
equipped
Encryption Type 2 Type of encryption being used When the
radio is secure
equipped
Control Head Version Control head firmware version number Always
Auxiliary Control Head Firmware version for the auxiliary control
head
When an
auxiliary
control head is
present
Siren Version Firmware version for the siren When a siren
is present
VRS Version Number Firmware version for the VRS When VRS is
present
Model Number The radio’s model number, as
programmed in the codeplug
Always
Serial Number The radio’s serial number, as programmed
in the codeplug
Always
ROM Size Memory capacity of the flash port Always
FLASHcode The FLASHcodes, programmed as a part
of the radio’s codeplug
Always
Note: All displays are temporary and will expire without any user
intervention. If the information is longer than the physical length
of the control head display, it will wrap around to the next display.
After the last display,
RF TEST will be displayed.
