June 11, 2003 6881096C73-O
8-32 Disassembly/Reassembly Procedures: Fastener Torque Chart
8.4 Fastener Torque Chart
Table 8-3 lists the various fasteners by part number and description, followed by the torque values
and the location where used. Torque all fasteners to the recommended value when assembling the
radio.
Table 8-3. Fastener Torque Chart
Part Number Description
Repair
Torque
(in.-lbs.)
Where Used
0310907A20 Screw, Torx M3x10 6-8 Mainboard (3), Secure Shield (2)
0385870E01 Screw, Torx M4x25 24-28 Top Cover (10)
0380077M07 Screw, Hex M3x35 6-8 Control head (2) and remote
interconnect (2) mounting
0310945A11 Screw, Plastite M3x16 6-8 Control Head and remote dash board
attachment (varies)
0310945A14 Screw, Plastite M3x8 6-8 Remote control cable cover
0310908A33 Screw, machine 6-8 Back housing W9 control head (3)
0380041S01 Screw, captive 6-8 Control head leaf spring (4)
0380077M04 Screw, hex M3x22 6-8 Remote cable mounting (2)
0384244C06 Wing Screw M5x10 12-16 Radio Mounting (2)
