6881096C73-O June 11, 2003
Model Numbering, Charts, and Specifications xix
ASTRO XTL 5000 3.5–35 Watt Model Chart
M20URS9PW1AN 764–870 MHz
Option Description
G66AA ADD: Dash Mount W4, W5, W7
G66AB ADD: Dash Mount W3
G66AC ADD: Dash Mount No Control Head Needed
G67AA ADD: Remote Mount W4, W5, W7
G67AB ADD: Remote Mount W9
G67AC ADD: Remote Mount W3
G67AE ADD: Remote Mount No Control Head
G72AA ADD: W3 Handheld Control Head
G73AA ADD: W4 Control Head
G79AA ADD: W5 Control Head
G80AA ADD: W7 Control Head
G81AA ADD: W9 Control Head
B977DU ADD: Control Head W9 Hdw
B977DV ADD: Control Head W7 G48AN and G806AF
B977DZ ADD: Control Head W9 G48AN and G806AF
B977EB INT: Control Head W4 Std Button
B977EC INT: Control Head W5 Std Button
B977ED INT: Control Head W7 Std Button
G239AR INT: Secure Button W7
G239AD INT: Secure Button W9
Item No. Description
X HUF4017_ 700-800 MHz Main Board
X
HHN4045_ 700-800 MHz Transceiver Hardware
XXXXXXX HLN6861_ Hardware Standard Install
XX
XXXXX HLN6863_ Accessory Connector
X
X HLN6864_ Control Head Dash Interconnect
XXX HKN4191_ Mobile Power Cable
X
XXXX HLN6185_ Hardware Remote CH
X
XXXX HLN6865_ Remote-Mount Control Head Hardware
X
X HLN6885_ Handheld CH Interconnect Board
XX X HLN6883_ Remote Interconnect Board
X HLN6813_ Control Head Trunnion Kit
X HLN6432_ Back Housing Kit
XXXX HKN4192_ Mobile Power Cable 20 ft.
X HLN4921_ Trunnion
X HMN4044_ Handheld Control Head
X AAMN4045_ W4 Control Head
XXX HLN6105_ Spare Button Kit
XXX HLN6688_ Spare Button Kit
X HLN6440_ W5 Control Head
XX HLN6396_ CH DEK Compatible
X HLN6441_ W7 Control Head
X HCN1078_ W9 Control Head (Black)
X HLN6481_ W9 Clear Button Kit
X HLN6476_ W9 Secure Button Kit
X HLN6549_ W4 Standard Button Map
X HLN6548_ W5 Standard Button Map
X HLN6523_ W7 Standard Button Map (Also see next page)
X X HLN6524_ W7 Secure Button Map
X HLN6800_ W9 Secure Button Kit
X = Item Included
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
