June 11, 2003 6881096C73-O
xx Model Numbering, Charts, and Specifications
ASTRO XTL 5000 3.5–35 Watt Model Chart (cont.)
M20URS9PW1AN 764–870 MHz
Option Description
G239AM INT: Secure Button W4
G239AN INT: Secure Button W5
G239AP INT: Secure Button W7 G50/51
G239AQ INT: Secure Button W9 G50/51
G159AC ADD: Encryption UCM Hardware
G159AD ADD: Encryption UCM Hdw 30 Sec Key Ret
W382AG ALT: Control Station Palm Microphone
W665BE ADD: Control Station Operation
G91AA ADD: Control Station Power Supply
W22AR ADD: W9 Palm Microphone
W22AS ADD: Hand Microphone
W109CS ALT: Microphone Handset with Hangup Cup
G110AB INT: 17 ft Control Head Cable W4, W5, W7, W9
G110AC INT: W3 Remote Y Cable
B18CL ADD: Auxiliary Spkr Spectra 5 Watt
W432AE ENH: 10 Watt Audio (Standard on High Power)
W484AD ADD: Antenna 3 dB Gain (764-870 MHz)
G335AT ADD: Antenna 1/4 Wave 764-870 MHz
G174AA ADD: Antenna 3 dB Low-Profile 764-870 MHz
G175AA ADD: Antenna 3 dB Elevat Feed 764-870 MHz
Item No. Description
X HLN6249_ W4 Secure Button Map
X
HLN6208_ W5 Secure Button Map
X HLN6523_ W7 Standard Button Map (Also see prev. pg)
X HLN6675_ W9 Secure Button Map
X HMN1050_ Control Station Microphone
X HLN6876_ Secure Interface Board 3 Day Key Retention
X HLN6877_ Secure Interface Board 30 Sec Key Retention
X HLN6042_ Base Tray
X HLN6047_ BDW Installation Base Tray
X HPN4001_ Control Station Power Supply
X HMN1061_ W9 Palm Microphone
X HMN1080_ Standard Palm Microphone W4, W5, W7
X HLN1220_ Microphone Handset with Hangup Clip
X HKN4356_ Standard 17 ft Control Head Remote Cable
X HKN6096_ Handheld Control Head Y Cable
X HSN4018_ Speaker 5 Watt
X HSN6001_ Speaker 10 Watt
X HAF4017_ Antenna 3 dB Gain 762-870 MHz
X HAF4016_ Antenna 1/4 Wave 762-870 MHz
X HAF4013_ Antenna 3 dB Low Profile 762-870 MHz
X HAF4014_ Antenna 3 dB Elevated Feed 762-870 MHz
X = Item Included
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
