6881096C73-O June 11, 2003
Model Numbering, Charts, and Specifications xxi
700–800 MHz Radio Specifications
GENERAL RECEIVER TRANSMITTER
FCC Designations: AZ492FT5823 Frequency Range: Frequency Range:
700 MHz Band: 764–776 MHz 700 MHz Band:
Temperature Range: 800 MHz Band: 851–870 MHz Repeater Mode: 794–806 MHz
Operating: –30° C to +60° C Talkaround Mode: 764–776 MHz
Storage: –40° C to +85° C Channel Spacing: 12.5 kHz/20 kHz/25 kHz 800 MHz Band:
Repeater Mode: 806–825 MHz
Power Supply: 12 Vdc Negative Ground Only Input Impedance: 50 ohm Talkaround Mode: 851–870 MHz
Battery Drain: (Maximum) Frequency Separation: Full Bandsplit Rated Output Power:
35 W: 764–806 MHz Band: 2***/30 W
Standby @ 13.8 V: 0.7 A Sensitivity: 806–870 MHz Band: 35 W
Receive at Rated Audio @ 13.8 V: 3.0 A 20 dB Quieting:
Transmit @ Rated Power: 25 kHz Channel Spacing: 0.30 µV Channel Spacing: 12.5 kHz/20 kHz/25 kHz
35 W 12.0 A 12 dB SINAD:
25 kHz Channel Spacing: 0.25 µV Output Impedance: 50 ohm
Dimensions (H x W x D)
W4, W5, and W7 Models: Digital Sensitivity**: Frequency Separation: Full Bandsplit
Remote-Mount Control Head: 2.0" x 7.1"x 2.2" 1% BER (12.5 kHz channel): 0.30 µV
(50.8 mm x 180.3 mm x 55.9 mm) 5% BER (12.5 kHz channel): 0.25 µV Frequency Stability*:
Dash-Mount Radio: 2.0" x 7.1"x 9.1" (–30° to +60°C; 25°C Ref.): ±0.00015%
(50.8 mm x 180.3 mm x 231.1 mm) Adjacent Channel Selectivity*:
W9 Model: 25 kHz Channel: 80 dB Modulation Limiting*:
Remote-Mount Control Head: 3.4" x 6.5"x 1.7" 12.5 kHz Channel: 65 dB 25 kHz Channel Spacing: ±5.0 kHz
(86.4 mm x 165.0 mm x 43.2 mm) 12.5 kHz Channel Spacing: ±2.5 kHz
Speaker: (excluding mounting bracket) Intermodulation*: 80 dB
5.5" x 5.5"x 2.5" Modulation Fidelity (C4FM)**:
(139.7 mm x 139.7 mm x 63.5 mm) Spurious Rejection*: 90 dB 12.5 kHz Digital Channel: ±2.8 kHz
Weight: Frequency Stability*: FM Hum and Noise*:
Radio: 6.1 lbs (2.8 kg) (–30° to +60° C; 25° C Ref.): ±0.00015% 20/25 kHz Channel: –40 dB
Speaker: 1.5 lbs (0.7 kg) 12.5 kHz Channel: –34 dB
Audio Output at 3% Distortion*:
7.5 Watts into 8 Ohms Emission (Conducted and Radiated):
13 Watts into 3.2 Ohms –70 dBc/–85 dBc (GNSS)
Audio Sensitivity*:
(For 60% Max. Deviation at 1 kHz):
0.08 V ±3 dB
Audio Response*:
(6 dB/Octave Pre-Emphasis 300 to 3000 Hz):
+1,–3 dB
Audio Distortion*: 2%
Emissions Designators:
8K10F1D, 8K10F1E, 11K0F3E, 16K0F3E, and
20K0F1E
Specifications subject to change without notice.
* Measured in analog mode per TIA/EIA 603 under nominal conditions.
** Measured in digital mode per TIA/EIA IS 102.CAAB.
*** 2 W. itinerant frequencies.
