June 11, 2003 6881096C73-O
4-2 Test Equipment, Service Aids, and Tools: Service Aids and Recommended Tools
Table 4-3 contains a listing of non-Motorola test equipment recommended for servicing mobile
radios.
4.2 Service Aids and Recommended Tools
Refer to the tables in this section for a listing and description of the service aids and tools designed
specifically for servicing this family of radios, as well as the more common tools required to
disassemble and properly maintain the radio. These kits and/or parts are available from the Motorola
parts division offices listed in Appendix A. Replacement Parts Ordering.
Table 4-3. Recommended Non-Motorola Test Equipment
Model Number Description Application
1:1 Audio Transformer Audio measurement (audio PA must NOT be grounded)
Agilent 6552 Power Supply (0-20 V, 0-25 A) Mobile radio power supply
Agilent 8901 Modulation Analyzer Frequency, reference oscillator deviation and
compensation measurements
Agilent 8903 Audio Analyzer Audio signal-level, SINAD, and distortion
measurements
Fluke 45 Bench-Top Digital Multimeter AC/DC voltage and current measurements
Fluke 187 or 189 Handheld Digital Multimeter
(True RMS, AC, AC+DC, dB)
AC/DC voltage and current measurements
Fluke 190 Series Handheld Oscilloscope
(60-200 MHz Bandwidth, 2.5 GS/
sec, Built-in 500-Count True
RMS Multimeter)
Waveform measurements
HP E4430 Digital I/Q Modulation Signal
Source
Signal source for transmit and receive digital tests
Weinschel 49 30 43 30 dB RF Attenuator For tests that require a modulation analyzer or
wattmeter
Table 4-4. Service Aids for XTL 5000 Board-Level Troubleshooting
Motorola
Part Number
Description Application
HKN6155 Programming Flash Cable Used with Tuner Software, CPS, and FLASHport
RVN4185 Customer Programming
Software and Tuner Software
Programming and radio alignment software on CD
