6881096C73-O June 11, 2003
Basic Maintenance: Handling Precautions 2-3
NOTE:Be sure that the table and floor mats are properly grounded.
When these items are not readily available, observing the following techniques will minimize the
chance of damage:
• If a static-sensitive device is to be temporarily set down, use a conductive surface for
placement of the device.
• Make skin contact with a conductive work surface first and maintain this contact when the
device is set down or picked up.
• Always wear a conductive wrist strap when servicing this equipment. The Motorola part number
for a replacement wrist strap that connects to the table mat is 42-80385A59.
• For additional information, refer to Service and Repair Note SRN-F1052, Static Control
Equipment for Servicing ESD Sensitive Products, available from the Literature Distribution
Center.
Motorola
Literature Distribution Center
2200 Galvin Drive, Suite 2218
Elgin, IL 60123
(847) 783-2522
(847) 783-2523/2524 (Fax)
