Video Controller
19-18 MPC823e REFERENCE MANUAL MOTOROLA
VIDEO CONTROLLER
19
BR—Blanking on Rising Edge of the Clock
0 = The value of the BLANK
signal will be 0 after the rising edge of the clock.
1 = The value of the BLANK
signal will be 1 after the rising edge of the clock.
BF—Blanking on Falling Edge of the Clock
0 = The value of the BLANK
signal will be 0 after the falling edge of the clock.
1 = The value of the BLANK
signal will be 1 after the falling edge of the clock.
Bits 8–13 and 17–18—Reserved
These bits are reserved and must be set to 0.
VDS—Video Data Select
This field selects the source of the video data or holds the last value of the data for the next
CNT cycle.
00 = Select active video from display frame buffer (FIFO output).
01 = Select inactive (background) video from the background color buffer.
10 = Hold last value of data.
11 = Reserved.
INT—Interrupt
0 = Do not generate a interrupt to the core.
1 = Generate a maskable interrupt (end of frame) after this entry completes and before
the next one begins.
Note: All pins are general-purpose and can be programmed according to your
requirements. The signal pin value only changes at the first cycle in which the
line is valid. If a line is valid for more than one clock (CNT > 1), the signal holds
its last assigned value.
