Development Capabilities and Interface
MOTOROLA MPC823e REFERENCE MANUAL 20-51
DEVELOPMENT
20
CAPABILITIES & INTERFACE
LW0IADC—First Load/Store Watchpoint Care/Don’t Care I-Address Events
0 = “Don’t care.”
1 = “Care.”
LW0LA—First Load/Store Watchpoint L-Address Events Selection
00 = Match from comparator E.
01 = Match from comparator F.
10 = Match from comparators E & F.
11 = Match from comparators E | F.
LW0LADC—First Load/Store Watchpoint Care/Don’t Care L-Address Events
0 = “Don’t care.”
1 = “Care.”
LW0LD—First Load/Store Watchpoint L-Data Events Selection
00 = Match from comparator G.
01 = Match from comparator H.
10 = Match from comparators G & H.
11 = Match from comparators G | H.
LW0LDDC—First Load/Store Watchpoint Care/Don’t Care L-Data Events
0 = “Don’t care.”
1 = “Care.”
LW1EN—Second Load/Store Watchpoint Enable
0 = Watchpoint not enabled (reset value).
1 = Watchpoint enabled.
LW1IA—Second Load/Store Watchpoint I-Address Watchpoint Selection
00 = First instruction watchpoint.
01 = Second instruction watchpoint.
10 = Third instruction watchpoint.
11 = Fourth instruction watchpoint.
LW1IADC—Second Load/Store Watchpoint Care/Don’t Care I-Address Event
0 = “Don’t care.”
1 = “Care.”
LW1LA—Second Load/Store Watchpoint L-Address Events Selection
00 = Match from comparator E.
01 = Match from comparator F.
10 = Match from comparators E & F.
11 = Match from comparators E | F.
LW1LADC—Second Load/Store Watchpoint Care/Don’t Care L-Address Events
0 = “Don’t care.”
1 = “Care.”
