IEEE 1149.1 Test Access Port
MOTOROLA MPC823e REFERENCE MANUAL 21-9
IEEE 1149.1 TEST
21
ACCESS PORT
67 IO.ctl G201.CTL — —
68 i.obs A[17] IO —
69 o.pin A[17] IO g201.ctl
70 i.obs A[19] IO —
71 o.pin A[19] IO g201.ctl
72 i.obs A[27] IO —
73 o.pin A[27] IO g201.ctl
74 i.obs A[20] IO —
75 o.pin A[20] IO g201.ctl
76 i.obs A[21] IO —
77 o.pin A[21] IO g201.ctl
78 i.obs A[24] IO —
79 o.pin A[24] IO g201.ctl
80 i.obs A[23] IO —
81 o.pin A[23] IO g201.ctl
82 i.obs A[29] IO —
83 o.pin A[29] IO g200.ctl
84 IO.ctl G200.CTL — —
85 i.obs A[25] IO —
86 o.pin A[25] IO g200.ctl
87 i.obs A[30] IO —
88 o.pin A[30] IO g200.ctl
89 i.obs A[18] IO —
90 o.pin A[18] IO g200.ctl
91 i.obs A[28] IO —
92
o.pin A[28] IO g200.ctl
93 i.obs A[22] IO —
94 o.pin A[22] IO g200.ctl
95 i.obs A[26] IO —
96 o.pin A[26] IO g200.ctl
97 i.obs A[31] IO —
98 o.pin A[31] IO g200.ctl
99 i.obs TSIZ0_REG_B IO —
100 o.pin TSIZ0_REG_B IO g204.ctl
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
