IEEE 1149.1 Test Access Port
21-10 MPC823e REFERENCE MANUAL MOTOROLA
IEEE 1149.1 TEST
21
ACCESS PORT
101
i.obs TSIZ1 IO —
102
o.pin TSIZ1 IO g204.ctl
103
IO.ctl G204.CTL — —
104
o.pin WE3_B_BSAB3_B_PCWEB O —
105
o.pin WE1_B_BSAB1_B_IOWR_B O —
106
o.pin WE2_B_BSAB2_B_PCOE_B O —
107
o.pin WE0_B_BSAB0_B_IORD_B O —
108
o.pin GPLA0_B_GPLB0_B O —
109
o.pin OE_B_GPLAB1_B O —
110
o.pin GPLAB2_B_CS2_B O —
111
o.pin GPLAB3_B_CS3_B O —
112
o.pin CS4_B O —
113
o.pin CS5_B O —
114
o.pin CS6_B_CE1B_B O —
115
o.pin CS7_B_CE2B_B O —
116
o.pin CS3_B O —
117
o.pin CS2_B O —
118
o.pin CS1_B O —
119
o.pin CS0_B O —
120
i.obs WR_B IO —
121
o.pin WR_B IO g96.ctl
122
IO.ctl G96.CTL — —
123
i.obs GPLB4_B_UPWAITB IO —
124
o.pin GPLB4_B_UPWAITB IO g24.ctl
125
IO.ctl G24.CTL — —
126
o.pin GPLA5_B O —
127
i.obs GPLA4_B_UPWAITA IO —
128
o.pin GPLA4_B_UPWAITA IO g25.ctl
129
IO.ctl G25.CTL — —
130
o.pin BDIP_B_GPLB5_B O —
131
i.obs BI_B IO —
132
o.pin BI_B IO g23.ctl
133
IO.ctl G23.CTL — —
134
i.obs TA_B IO —
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
To Next Page
