IEEE 1149.1 Test Access Port
MOTOROLA MPC823e REFERENCE MANUAL 21-11
IEEE 1149.1 TEST
21
ACCESS PORT
135
o.pin TA_B IO g22.ctl
136
IO.ctl G22.CTL — —
137
i.obs TEA_B IO —
138
o.pin TEA_B IO g89.ctl
139
IO.ctl G89.CTL — —
140
i.obs TS_B IO —
141
o.pin TS_B IO g97.ctl
142
IO.ctl G97.CTL — —
143
i.obs BR_B IO —
144
o.pin BR_B IO g21.ctl
145
IO.ctl G21.CTL — —
146
i.obs BG_B IO —
147
o.pin BG_B IO g20.ctl
148
IO.ctl G20.CTL — —
149
i.obs BB_B IO —
150
o.pin BB_B IO g11.ctl
151
IO.ctl G11.CTL — —
152
i.obs FRZ_IRQ6_B IO —
153
o.pin FRZ_IRQ6_B IO g90.ctl
154
IO.ctl G90.CTL — —
155
i.obs BURST_B IO —
156
o.pin BURST_B IO g205.ctl
157
IO.ctl G205.CTL — —
158
i.obs RSV_B_IRQ2_B IO —
159
o.pin RSV_B_IRQ2_B IO g17.ctl
160
IO.ctl G17.CTL — —
161
i.obs IPB5_LWP1_VF1 IO —
162
o.pin IPB5_LWP1_VF1 IO g15.ctl
163
IO.ctl G15.CTL — —
164
i.obs IPB4_LWP0_VF0 IO —
165
o.pin IPB4_LWP0_VF0 IO g150.ctl
166
IO.ctl G150.CTL — —
167
i.obs IPB3_IWP2_VF2 IO —
168
o.pin IPB3_IWP2_VF2 IO g151.ctl
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
