IEEE 1149.1 Test Access Port
21-12 MPC823e REFERENCE MANUAL MOTOROLA
IEEE 1149.1 TEST
21
ACCESS PORT
169
IO.ctl G151.CTL — —
170
i.obs IPB1_IWP1_VFLS1 IO —
171
o.pin IPB1_IWP1_VFLS1 IO g150.ctl
172
i.obs IPB0_IWP0_VFLS0 IO —
173
o.pin IPB0_IWP0_VFLS0 IO g150.ctl
174
i.obs IPB7_PTR_AT3 IO —
175
o.pin IPB7_PTR_AT3 IO g13.ctl
176
IO.ctl G13.CTL — —
177
i.obs IPB2_IOIS16B_B_AT2 IO —
178
o.pin IPB2_IOIS16B_B_AT2 IO g41.ctl
179
IO.ctl G41.CTL — —
180
i.obs ALEB_DSCK_AT1 IO —
181
o.pin ALEB_DSCK_AT1 IO g16.ctl
182
IO.ctl G16.CTL — —
183
i.obs IPB6_DSDI_AT0 IO —
184
o.pin IPB6_DSDI_AT0 IO g14.ctl
185
IO.ctl G14.CTL — —
186
i.obs KR_B_IRQ4_B_SPKROUT IO —
187
o.pin KR_B_IRQ4_B_SPKROUT IO g95.ctl
188
IO.ctl G95.CTL — —
189
i.obs OP2_MODCK1_STS_B IO —
190
o.pin OP2_MODCK1_STS_B IO g92.ctl
191
IO.ctl G92.CTL — —
192
i.obs OP3_MODCK2_DSDO IO —
193
o.pin OP3_MODCK2_DSDO IO g91.ctl
194
IO.ctl G91.CTL — —
195
i.obs CLK4IN I —
196
o.pin TEXP O —
197
i.obs HRESET_B IO —
198
o.pin HRESET_B IO g94.ctl
199
IO.ctl G94.CTL — —
200
i.obs SRESET_B IO —
201
o.pin SRESET_B IO g93.ctl
202
IO.ctl G93.CTL — —
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
To Next Page
