IEEE 1149.1 Test Access Port
21-14 MPC823e REFERENCE MANUAL MOTOROLA
IEEE 1149.1 TEST
21
ACCESS PORT
237 o.pin D[22] IO g102.ctl
238 i.obs D[6] IO —
239 o.pin D[6] IO g102.ctl
240 i.obs D[20] IO —
241 o.pin D[20] IO g102.ctl
242 i.obs D[19] IO —
243 o.pin D[19] IO g102.ctl
244 i.obs D[18] IO —
245 o.pin D[18] IO g102.ctl
246 i.obs D[15] IO —
247 o.pin D[15] IO g102.ctl
248 i.obs D[16] IO —
249 o.pin D[16] IO g102.ctl
250 i.obs D[5] IO —
251 o.pin D[5] IO g101.ctl
252 IO.ctl G101.CTL — —
253 i.obs D[3] IO —
254 o.pin D[3] IO g101.ctl
255 i.obs D[14] IO —
256 o.pin D[14] IO g101.ctl
257 i.obs D[2] IO —
258 o.pin D[2] IO g101.ctl
259 i.obs D[11] IO —
260 o.pin D[11] IO g101.ctl
261 i.obs D[10] IO —
262 o.pin D[10] IO g101.ctl
263 i.obs D[9] IO —
264 o.pin D[9] IO g101.ctl
265 i.obs D[17] IO —
266 o.pin D[17] IO g101.ctl
267 i.obs D[27] IO —
268 o.pin D[27] IO g100.ctl
269 IO.ctl G100.CTL — —
270 i.obs D[23] IO —
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
