Motorola MPC823e - Page 1136

IEEE 1149.1 Test Access Port
MOTOROLA MPC823e REFERENCE MANUAL 21-15
IEEE 1149.1 TEST
21
ACCESS PORT
271 o.pin D[23] IO g100.ctl
272 i.obs D[1] IO —
273 o.pin D[1] IO g100.ctl
274 i.obs D[4] IO —
275 o.pin D[4] IO g100.ctl
276 i.obs D[0] IO —
277 o.pin D[0] IO g100.ctl
278 i.obs D[12] IO —
279 o.pin D[12] IO g100.ctl
280 i.obs D[8] IO —
281 o.pin D[8] IO g100.ctl
282 i.obs D[13] IO —
283 o.pin D[13] IO g100.ctl
284 i.obs IRQ0_B I —
285 i.obs IRQ1_B I —
286 i.obs IRQ7_B I —
287 i.obs SPARE3 IO —
288 o.pin SPARE3 IO g10.ctl
289 IO.ctl G10.CTL — —
290 i.obs PD[3] IO —
291 o.pin PD[3] IO g9.ctl
292 IO.ctl G9.CTL — —
293 i.obs PD[5] IO —
294 o.pin PD[5] IO g8.ctl
295 IO.ctl G8.CTL — —
296 i.obs PD[6] IO —
297 o.pin PD[6] IO g7.ctl
298 IO.ctl G7.CTL — —
299 i.obs PD[4] IO —
300 o.pin PD[4] IO g6.ctl
301 IO.ctl G6.CTL — —
302 i.obs PD[7] IO —
303 o.pin PD[7] IO g5.ctl
304 IO.ctl G5.CTL — —
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
