Motorola MPC823e - Page 1137

IEEE 1149.1 Test Access Port
21-16 MPC823e REFERENCE MANUAL MOTOROLA
IEEE 1149.1 TEST
21
ACCESS PORT
305 i.obs PD[8] IO —
306 o.pin PD[8] IO g4.ctl
307 IO.ctl G4.CTL — —
308 i.obs PD[9] IO —
309 o.pin PD[9] IO g3.ctl
310 IO.ctl G3.CTL — —
311 i.obs PD[10] IO —
312 o.pin PD[10] IO g2.ctl
313 IO.ctl G2.CTL — —
314 i.obs PD[11] IO —
315 o.pin PD[11] IO g1.ctl
316 IO.ctl G1.CTL — —
317 i.obs PD[12] IO —
318 o.pin PD[12] IO g81.ctl
319 IO.ctl G81.CTL — —
320 i.obs PD[13] IO —
321 o.pin PD[13] IO g80.ctl
322 IO.ctl G80.CTL — —
323 i.obs PD[14] IO —
324 o.pin PD[14] IO g79.ctl
325 IO.ctl G79.CTL — —
326 i.obs PD[15] IO —
327 o.pin PD[15] IO g78.ctl
328 IO.ctl G78.CTL — —
329 i.obs PC[4] IO —
330 o.pin PC[4] IO g26.ctl
331 IO.ctl G26.CTL — —
332 i.obs PC[5] IO —
333 o.pin PC[5] IO g27.ctl
334 IO.ctl G27.CTL — —
335 i.obs PB[16] IO —
336 o.pin PB[16] IO g40.ctl
337 IO.ctl G40.CTL — —
338 i.obs PC[6] IO —
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
