IEEE 1149.1 Test Access Port
MOTOROLA MPC823e REFERENCE MANUAL 21-17
IEEE 1149.1 TEST
21
ACCESS PORT
339 o.pin PC[6] IO g28.ctl
340 IO.ctl G28.CTL — —
341 i.obs PB[17] IO —
342 o.pin PB[17] IO g47.ctl
343 IO.ctl G47.CTL — —
344 i.obs PC[7] IO —
345 o.pin PC[7] IO g29.ctl
346 IO.ctl G29.CTL — —
347 i.obs PA[4] IO —
348 o.pin PA[4] IO g66.ctl
349 IO.ctl G66.CTL — —
350 i.obs PB[18] IO —
351 o.pin PB[18] IO g48.ctl
352 IO.ctl G48.CTL — —
353 i.obs PA[5] IO —
354 o.pin PA[5] IO g67.ctl
355 IO.ctl G67.CTL — —
356 i.obs PB[19] IO —
357 o.pin PB[19] IO g49.ctl
358 IO.ctl G49.CTL — —
359 i.obs PA[6] IO —
360 o.pin PA[6] IO g68.ctl
361 IO.ctl G68.CTL — —
362 i.obs PC[8] IO —
363 o.pin PC[8] IO g30.ctl
364 IO.ctl G30.CTL — —
365 i.obs PA[7] IO —
366 o.pin PA[7] IO g69.ctl
367 IO.ctl G69.CTL — —
368 i.obs PC[9] IO —
369 o.pin PC[9] IO g31.ctl
370 IO.ctl G31.CTL — —
371 i.obs PA[8] IO —
372 o.pin PA[8] IO g70.ctl
Table 21-1. Boundary Scan Bit Definition (Continued)
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
