Memory Controller
15-80 MPC823e REFERENCE MANUAL MOTOROLA
MEMORY CONTROLLER
15
Figure 15-44. Burst Read Access To Page Mode DRAM (No LOOP)
cst4 Bit 0 0 00000000
cst1 Bit 1 0 00000000
cst2 Bit 2 0 00000001
cst3 Bit 3 0 00000001
bst4 Bit 4 1 10101010
bst1 Bit 5 1 00000000
bst2 Bit 6 1 01010101
bst3 Bit 7 1 01010101
g0l0 Bit 8
g0l1 Bit 9
g0h0 Bit 10
g0h1 Bit 11
g1t4 Bit 12
g1t3 Bit 13
g2t4 Bit 14
g2t3 Bit 15
g3t4 Bit 16
g3t3 Bit 17
g4t4 Bit 18
g4t3 Bit 19
g5t4 Bit 20
g5t3 Bit 21
- Bit 22
- Bit 23
loop Bit 24 0 00000000
exen Bit 25 0 01010100
amx0 Bit 26 0 00000001
amx1 Bit 27 0 00000000
na Bit 28 0 01010100
uta Bit 29 1 01010101
todt Bit 30 0 00000001
last Bit 31 0 00000001
RBS RBS+1 RBS+2 RBS+3 RBS+4 RBS+5 RBS+6 RBS+7 RBS+8
CLKOUT/GCLK2
GCLK1
A[6:31]
TS
RD/ WR
D[0:31]
TA
CS1
BS_A [0:3]
ROW COLUMN 1 COLUMN 2 COLUMN 3 COLUMN 4
(
CAS [0:3])
(
RAS )
