Introduction
1-4 MPC823e REFERENCE MANUAL MOTOROLA
INTRODUCTION
1
• Memory Controller (Eight Banks)
❏ Contains Complete DRAM Controller
❏ Each Bank Can Be a Chip-Select or RAS
to Support a DRAM Bank
❏ A Maximum of 30 Wait States per Memory Bank Can Be Programmed
❏ Glueless Interface to DRAM Single In-Line Memory Modules, Static RAM,
Electrically Programmable Read-Only Memory, Flash EPROM or Synchronous
DRAM
❏ Four CAS
lines, Four WE lines, and One OE Line
❏ Boot Chip-Select Available at Reset (Options for 8-, 16-, or 32-Bit Memory)
❏ Variable Block Sizes—32K to 256M
❏ Selectable Write Protection
• System Integration Unit
❏ Hardware Bus Monitor
❏ Software Watchdog Timer
❏ Periodic Interrupt Timer
❏ Low-Power Stop Mode
❏ Clock Synthesizer
❏ On-Chip Bus Arbitration Logic
❏ PowerPC Decrementer
❏ PowerPC Timebase
❏ Real-Time Clock
❏ Reset Controller
• Video/LCD Controller
❏ Video Controller
— Supports Digital TFT LCD Panels and Analog NTSC/PAL Displays
— Sequential RGB, 4:4:4, and 4:2:2 YC r
C
b
(CCIR 601) Digital Component
Video Formats
— CCIR-656 Compatible 8-Bit Interface Port
— Horizontal Sync, Vertical Sync, Field and Blanking Timing Generation with
Half-Clock Resolution and Programmable Polarity
— Supports Interlace/Noninterlace Scanning Methods
— Programmable Display Active Area
— Programmable Background Color for Inactive Area
— Glueless Interface for Most Digital Video Encoders
— Uses Burst Read DMA Cycles for Maximum Bus Performance
— End-of-Frame Interrupt Generation
