Memory Map
3-8 MPC823e REFERENCE MANUAL MOTOROLA
MEMORY MAP
3
9D0 RCTR3—RISC Controller Trap Register 3 16 —
9D2 RCTR4—RISC Controller Trap Register 4 16 —
9D4 to 9D5 RES—Reserved — —
9D6 RTER—RISC Timer Event Register 16 16-23
9D8 to 9D9 RES—Reserved — —
9DA to 9DB RTMR—RISC Timer Mask Register 16 16-23
9DC to 9EF RES—Reserved — —
BAUD RATE GENERATORS
9F0 BRGC1—BRG1 Configuration Register 32 16-160
9F4 BRGC2—BRG2 Configuration Register 32 16-160
9F8 BRGC3—BRG3 Configuration Register 32 16-160
9FC BRGC4—BRG4 Configuration Register 32 16-160
UNIVERSAL SERIAL BUS
A00 USMOD—USB Mode Register 8 16-365
A01 USADR—USB Slave Address Register 8 16-371
A02 USCOM—USB Command Register 8 16-372
A03 RES—Reserved 8 —
A04 USEP0—USB Endooint Configuration 0 Register 16 16-373
A06 USEP1—USB Endooint Configuration 1 Register 16 16-373
A08 USEP2—USB Endooint Configuration 2 Register 16 16-373
A0A USEP3—USB Endooint Configuration 3 Register 16 16-373
A0C to A0F RES—Reserved — —
A10 USBER—USB Event Register 16 16-376
A12 RES—Reserved 16 —
A14 USBMR—USB Mask Register 16 16-377
A16 RES—Reserved 8 —
A17 USBS—USB Status Register 8 16-377
A18 to A1F RES—Reserved — —
Table 3-1. MPC823e Internal Memory Map (Continued)
INTERNAL
ADDRESS REGISTER
SIZE
(IN BITS)
PAGE NUMBER
LOCATION
