Communication Processor Module
16-505 MPC823e REFERENCE MANUAL MOTOROLA
CPIC
COMMUNICATION
16
PROCESSOR MODULE
Table 16-46. Encoding the Interrupt Vector
INTERRUPT
NUMBER
INTERRUPT SOURCE
DESCRIPTION
INTERRUPT VECTOR
1F Parallel I/O—PC15 11111
1E USB 11110
1D SCC2 11101
1C SCC3 11100
1B Reserved 11011
1A Parallel I/O—PC14 11010
19 Timer 1 11001
18 Parallel I/O—PC13 11000
17 Parallel I/O—PC12 10111
16 SDMA Channel Bus Error 10110
15 IDMA1 10101
14 IDMA2 10100
13 Reserved 10011
12 Timer 2 10010
11 RISC Timer Table 10001
10
I
2
C
10000
F Parallel I/O—PC11 01111
E Parallel I/O—PC10 01110
D Reserved 01101
C Timer 3 01100
B Parallel I/O—PC9 01011
A Parallel I/O—PC8 01010
9 Parallel I/O—PC7 01001
8 Reserved 01000
7 Timer 4 00111
6 Parallel I/O—PC6 00110
5 SPI 00101
4 SMC1 00100
3 SMC2 00011
2 Parallel I/O—PC5 00010
1 Parallel I/O—PC4 00001
0 Error 00000
