PCMCIA Interface
17-16
MPC823e REFERENCE MANUAL
MOTOROLA
PCMCIA INTERFACE
17
CBOE—Card B Output Enable
The value of this bit is always reflected on the OP2 pin. When the PCMCIA controller is in
active mode, POE_B
is connected to the OP2 pin. POE_B is used to three-state the address
and strobe pins addressing the PCMCIA card slot. Refer to
Section 17.3.3 The PCMCIA
Output Port Signals
.
0 = POE_B
is asserted if the PCMCIA controller is active.
1 = POE_B
is not asserted if the PCMCIA controller is active.
CBRESET—Card B Reset
The value of this bit is always reflected on the OP3 pin. When the PCMCIA controller is in
active mode, RESET_B is connected to the OP3 pin. RESET_B is used to place the
PCMCIA card in its default (memory-only interface) state, and initiate the beginning of any
further card initialization. Refer to
Section 17.3.3 The PCMCIA Output Port Signals
.
0 = RESET_B is not asserted if the PCMCIA controller is active.
1 = RESET_B is asserted if the PCMCIA controller is active.
Bits 26–31—Reserved
These bits are reserved and must be set to 0.
17.5.5 PCMCIA Base Registers
The PCMCIA base registers 0–7 (PBR0-7) contain the PCMCIA base addresses for the
PCMCIA memory or I/O windows. The base registers are used in conjunction with the BSIZE
field of the corresponding PCMCIA option register to ensure valid PCMCIA accesses.
PBA—PCMCIA Base Address
PBR0–PBR7
BIT
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
FIELD PBA
RESET —
R/W R/W
ADDR
(IMMR & 0xFFFF0000) + 0x80 (PBR0), 0x88 (PBR1), 0x90 (PBR2), 0x98 (PBR3),
0xA0 (PBR4), 0xA8 (PBR5), 0xB0 (PBR6), 0xB8 (PBR7)
BIT 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
FIELD PBA
RESET —
R/W R/W
ADDR
(IMMR & 0xFFFF0000) + 0x80 (PBR0), 0x88 (PBR1), 0x90 (PBR2), 0x98 (PBR3),
0xA0 (PBR4), 0xA8 (PBR5), 0xB0 (PBR6), 0xB8 (PBR7)
NOTE: — = Undefined.
