MUTOH VJ-1624 User Manual

4 Handling the printer VJ-1624 OPERATION MANUAL
4-36
18. Press the [Enter] key.
• "Wait for a while..." is displayed on the operation panel.
• "Remove white plate then close mainte. cover." is displayed on the operation panel.
19. Remove the white reference plate from the plate installation place, turn it over so that the black side
faces up, and install it back to the original place.
NOTE
• When the white reference plate is not in use, make sure that it is turned over facing down to
avoid any contamination.
No. Name
1 Connector cap
2Tabs
3 Print head section
4 Connector
No. Name
1 White reference plate
2 Plate installation place
1
1
2
2
3
