3 Before using VJ-1624 OPERATION MANUAL
3-26
3.4 Loading media
This section explains how to load and set media, and settings for each media type.
NOTE
• Refer to the following for details about handling media.
4.2 Media
• For details of the recommended media, contact your local MUTOH dealer.
3.4.1 Loading roll media
This section describes the procedure to load the roll media.
Put the roll media in the center.
NOTE
• The following roll media can be loaded to this printer.
• Media tube with a diameter of three inches: Less than 150mm in outer diameter, less than 30kg
in weight
• Media tube with a diameter of two inches: Less than 150mm in outer diameter, less than 30kg in
weight
Follow the procedure below to load the roll media.
1. Loosen the fixing levers on the right and left side of the rear. Set the distance between the roll media
holders wider than the roll media width.
