VJ-1624 OPERATION MANUAL 2 Product overview
2-5
2.2.3 Operation panel
Used to set the operating conditions, to display the status of the printer, and to set various functions.
Names of each operation key and status display along with the functions are explained.
TIP
• Refer to the following for details regarding the operation method of the operation panel.
• When setting the menu from the operation panel: 4.3 Menu setups on the operation panel
• When performing various operations in the operation panel: 4.4 Operating from the operation panel
No. Name Function
1 Roll media holder Load the roll media.
The flanges to attach roll media and the fixing levers to fix the roll media holders are
included.
2 Media feed slot Used for feeding media.
3 Ink cartridge slot Insert the ink cartridge.
4 Media guide Used for feeding media smoothly when the media is set or printed.
The heater (pre-heater) to warm up the media is installed inside.
5 AC inlet Used for connecting the power cable.
6 Network interface cable
connector
Connects a network interface cable.
7 Waste fluid valve Open and close when discharging the waste fluid from the waste fluid tank.
It is normally closed.
To Next Page
