MUTOH VJ-1624 - Custom Micro Adjustment Pattern

3 Before using VJ-1624 OPERATION MANUAL
3-60
NOTE
• When you press the [Cancel] key, the input operation is not executed and "Adj.2: Rough
Pattern" is displayed on the operation panel.
7. Press the [Enter] key on the operation panel.
• The value is set in the "Pattern A: *" (* indicates a number from 1 to 11).
8. In the same way, enter the numbers for "Patterns B" to "Pattern F".
• Press the [Enter] key to set the values.
• Once all set values have been entered, press the [Enter] key to register the set values of "Pattern
A" to "Pattern F" to the printer.
• The operation panel display returns to "Adj.2: Rough Pattern".
3.6.2.3 Custom Micro Adjustment Pattern
Check the confirmation pattern, and when the misalignment is small, perform micro adjustment.
This menu is made up with the following menus.
