VJ-1624 OPERATION MANUAL 3 Before using
3-59
• A rough adjustment pattern for print quality adjustment is printed after warming up.
• The pattern images are printed on both paper edges and the center of the media.
• Six rough adjustment patterns will be printed. Input setting value for each pattern.
4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the
number from 1 to 11 that is not out of alignment.
• "3" is selected in the next printing sample of "Micro Adjustment Pattern A".
• "5" is selected in the next printing sample of "Micro Adjustment Pattern B".
• "4" is selected in the next printing sample of "Micro Adjustment Pattern F".
NOTE
• "6" is the current setting value.
5. "PatternA: 6" is displayed on the operation panel.
6. Press the [+] key or [–] key to enter the number that you selected in Step 4.
To Next Page
