4 Handling the printer VJ-1624 OPERATION MANUAL
4-6
4.2.5 Head height adjustment
Printing with high printing rate or using strongly-curved media can cause print heads to rub.
Changing the distance from the print head surface to media(head height) may allow you to avoid head
rub.
Head height can be changed to two levels.
Follow the procedure below to change the head height.
4.2.5.1 When raising the print head
NOTE
• If the head height adjustment lever is raised, high print quality is not guaranteed.
• Do not open the front cover or change the head height during printing.
If the head height is changed, the alignment will be changed and high print quality will not be
guaranteed.
1. Open the front cover.
No. Name
1 Front cover
a
c
bd
Printable Area
a=Max. 15mm
b=5mm to 25mm
c=5mm
d=5mm to 25mm
Media feeding direction
1
