5 Panel setup menu VJ-1624 OPERATION MANUAL
5-8
*1 The default value of the effect differs depending on the selected print mode as shown below.
5.1.1.1.3 Adjust Print menu
Sets up when adjusting the printer for the optimum quality of image print.
This setting is different for each user type setting.
Setup item Setting Description
Effect <None> *1 The Effect function is not used.
Wave The printing joint will be the wave form.
The print quality may be improved than None.
<Fog> *1 The printing joint will shade off.
Set up this menu when obvious white lines or uneven print
density appear on printed media in "Wave".
Mode for low resolution (360 x 720dpi).
<Fine & Fuzz> *1 The printing joint will shade off as the wave form.
Perform the printing at slower speed than "Wave".
<Fine & Fog> *1 The printing joint will shade off. Set up this menu to improve
horizontal banding with Fine & Fuzz.
Performs the printing at a slower speed than Fine & Fuzz.
A-S.Fine & Wave Performs Wave printing using the half of the print head
nozzles.
Since only half of the print head nozzles are used, printing
speed becomes a half of Wave.
Set up this menu to improve the print quality compared with
"Fine & Fuzz". If used when one side of the nozzles are
clogged, quality deterioration may be avoided.
B-S.Fine & Wave Performs "Wave" printing using the half of the print head
nozzles on the opposite side of "A-S.Fine & Wave".
Since only half of the print head nozzles are used, printing
speed becomes a half of Wave.
Set up this menu to improve the print quality compared with
"Fine & Fuzz". If used when one side of the nozzles are
clogged, quality deterioration may be avoided.
— • [Enter] key: saves the setting and shifts to the previous
menu.
• [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1 Setup menu
Print Mode Effect Default Value
Quality 1 to 4 Fine & Fuzz
Graphics 1 to 2 Fine & Fuzz
Graphics 3 to 4 Fine & Fog
Banner 1 to 2 Fog
Banner 3 to 4 None
