VJ-1624 OPERATION MANUAL 5 Panel setup menu
5-9
NOTE
• This printer was adjusted at the factory shipment so that it obtains the optimum printing quality.
Adjust the quality if the print quality changes after the installation environment or the media is
changed.
• After performing Standard adjust print and changing the user type setting, make sure to perform
Adjust print.
• When performing Custom adjust print, the print modes are adjusted all at once. Therefore, you do
not need to perform print adjustment even when the user type setting has been newly set or changed.
• When using RIP software, etc, and setting the resolution which is different from the setting in the
user type setting, make sure to perform adjustment for all print modes by Custom Adjust Print.
Standard Adjust Print Menu
Adjusts only the print mode in the user type setting which is currently set.
Custom Adjust Print Menu
All patterns from A to F can be adjusted.
By performing this adjustment, all print modes will be adjusted.
Setup item Setting Description
Confirmation pattern Standard Adjusts the print mode in the user type setting which is
currently set only.
Standard Adjust Print Menu
Custom Adjusts all print modes.
Custom Adjust Print Menu
— [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1 User Type menu
Setup item Setting Description
Standard Standard Confirmation
Pattern
Print the test pattern for the alignment.
Check before adjusting.
3.6.1.1 Standard Confirmation Pattern
Standard Rough Adjustment
Pattern
Perform this adjustment when the misalignment is big.
Print adjustment patterns and enter the set values.
3.6.1.2 Standard Rough Adjustment Pattern
Standard Micro Adjustment
Pattern
Perform this adjustment when the misalignment is small.
Print adjustment patterns and enter the set values.
3.6.1.3 Standard Micro Adjustment Pattern
— • [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.3 Adjust Print menu
