5 Panel setup menu VJ-1624 OPERATION MANUAL
5-10
5.1.1.1.4 Media feed compensation
Sets up various settings on the media feed compensation.
Setup item Setting Description
Custom Custom Confirmation Pattern Print the confirmation patterns A to F for print adjustment.
Check before adjusting.
3.6.2.1 Custom Confirmation Pattern
Custom Rough Adjustment
Pattern
Perform this adjustment when the misalignment is big.
Print the confirmation patterns A to F and enter the set value.
3.6.2.2 Custom Rough Adjustment Pattern
Adjust Pattern ALL Perform this adjustment when the misalignment is small.
Print the confirmation patterns A to F and enter the set value.
3.6.2.3.1 Adj. PatternALL
Adjust Pattern A When the misalignment is small, select and print one of the
adjust patterns A to F and register the set value.
3.6.2.3.2 Each Adjust Patterns
Adjust Pattern B
Adjust Pattern C
Adjust Pattern D
Adjust Pattern E
Adjust Pattern F
— • [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.3 Adjust Print menu
Setup item Setting Description
PF Init.Adj.Print Performs initial adjustment printing.
• [Enter] key: shifts to the sub menu.
(1) Init.Adj.Print menu
Init.Adj.Change Sets up Initial Adjust Change.
• [Enter] key: shifts to the sub menu.
(2) Init.Adj.Change menu
Confirm Print Performs Confirm Print.
• [Enter] key: shifts to the sub menu.
(3) Confirm Print menu
Micro Adj. Print Performs Micro Adjustment Print.
• [Enter] key: shifts to the sub menu.
(4) Micro Adj. Print menu
Micro Adj.Change Sets up Micro Adjustment Change.
• [Enter] key: shifts to the sub menu.
(5) Micro Adj.Change menu
— • [Cancel] key: shifts to the previous menu.
5.1.1.1 User Type menu
To Next Page
