8 Appendix VJ-1624 OPERATION MANUAL
8-2
8.1 Product specifications
8.1.1 Printer specifications
Items Specification
Model name VJ-1624
Printing method On-demand piezo drive system
Drive system Firmware servo/DC motor drive
Media feed system Multipoint pressurizing grid roller system
Media fixing system Pressurization roller down system by manual lever
Media feed/ejection Rear feed/Front ejection
Roll media outer diameter 150mm or less
Roll media weight 30kg or less
Maximum media length 50m
Maximum media width 1,625mm
Minimum media width 900mm
Maximum media thickness 0.3mm (when the head height is Low)/1.3mm (when the head height is High)
Maximum printable media width 1,615mm
Print margin Front: Maximum of 30mm, Rear: 5mm (102mm at the roll media end), Left:
5mm to 25mm, Right: 5mm to 25mm
Media cut system Horizontal auto cut system / manual cut system
Head height adjustment Two adjustable positions of Low/High
CPU 64-bit RISC CPU
Memory 128MB
Command MH-RTL (RTL-PASS)
Interface Network interface (Ethernet IEEE 802.3)
Ink Supply system Supplied through tubes from four-color independent cartridges
Cartridges Black, Cyan, Magenta, Yellow: 220ml ± 5ml each or 440ml ±5ml (1000ml
±5ml when the optional high capacity pack adapter is used)
To Next Page
