E Series Automated Dispensing System
102 www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
14 Loop
Loop
------------------------------
Label: 1
Count: 1
[F1] OK
Key Press Function
>
Executes a group of commands for the specied number of times (Count).
Parameter Description
Label The address number the program jumps to. The jump-to address must occur
before the current address.
Count The number of times to execute the loop.
Range: 1–9999
15 Dispense Port
Dispense Port
------------------------------
Port: 0.3.5.7
Default: 0 Range: 0-8
Multi-out ex: 0.1.2
[F1] OK
Key Press Function
>
Sets the output port for the dispense valve signal. Use this command at the beginning of a program
to set the dispense port or immediately before a dispense command. If the system includes multiple
valves, you can specify multiple dispense ports, as shown in the example above (Multi-out ex: 0.1.2).
Default: 0
Range: 0-8
Appendix A, Type Menu Reference (continued)
